FastAPI RealWorld Example

Overview

#

A implementation of the RealWorld specification, a blogging platform similar to Medium, built with FastAPI. The project integrates a full observability stack, hardened container images, and automated CI/CD pipelines. It serves as a reference for building scalable, maintainable, and observable Python backend services.

• Source code: github.com/luizcarloscf/fastapi-realworld-example
• Tools: Python, FastAPI, SQLModel, Alembic, PostgreSQL, Docker, GitHub Actions, OpenTelemetry, Jaeger, Prometheus, OpenSearch, Grafana

sequenceDiagram
    participant User
    participant Conduit Backend
    participant PostgreSQL
    participant Otel Collector
    participant Jaeger
    participant OpenSearch
    participant Prometheus
    participant Grafana

    User->>Conduit Backend: Requests
    Conduit Backend->>PostgreSQL: Interacts with database
    Conduit Backend->>User: Responses
    Conduit Backend->>Otel Collector: Exposes metrics, traces, and logs
    Otel Collector->>Jaeger: Stores traces
    Otel Collector->>OpenSearch: Stores logs
    Otel Collector->>Prometheus: Stores metrics
    Jaeger->>Grafana: Provides traces
    OpenSearch->>Grafana: Provides logs
    Prometheus->>Grafana: Provides metrics
    Grafana->>User: Displays monitoring dashboard

Backend

#

The API is built with FastAPI following a layered architecture: routes, service, models, schemas, and core configuration. Data persistence uses PostgreSQL with SQLModel as the ORM, combining SQLAlchemy 2.0 async engine with Pydantic v2 validation, and Alembic for schema migrations.

• Framework: FastAPI with async request handling
• ORM: SQLModel (SQLAlchemy 2.0 + Pydantic v2)
• Migrations: Alembic
• Database: PostgreSQL

Authentication is implemented with JWT, and the codebase enforces static typing throughout using mypy, with flake8 and isort for linting and import ordering enforced via pre-commit hooks.

Observability

#

The entire observability stack is instrumented through OpenTelemetry, with the collector routing signals to dedicated backends:

• Traces: Jaeger for distributed tracing across requests
• Metrics: Prometheus for time series collection exposed via /metrics
• Logs: OpenSearch for structured log aggregation and querying
• Dashboards: Grafana for unified visualization of all signals

This setup mirrors a real production environment, allowing end to end traceability from HTTP request to database query.

graph TB
subgraph tdf[Telemetry Data Flow]
    subgraph subgraph_padding [ ]
        style subgraph_padding fill:none,stroke:none;
        subgraph od[Conduit]
        ms(FastAPI Backend)
        end

        ms -.->|"OTLP
gRPC"| oc-grpc

        subgraph oc[OTel Collector]
            style oc fill:#97aef3,color:black;
            oc-grpc[/"OTLP Receiver
listening on
grpc://localhost:4317"/]
            oc-proc(Processors)
            oc-spanmetrics[/"Span Metrics Connector"/]
            oc-prom[/"OTLP HTTP Exporter"/]
            oc-otlp[/"OTLP Exporter"/]
            oc-opensearch[/"OpenSearch Exporter"/]

            oc-grpc --> oc-proc
            oc-proc --> oc-prom
            oc-proc --> oc-otlp
            oc-proc --> oc-opensearch
            oc-proc --> oc-spanmetrics
            oc-spanmetrics --> oc-prom
        end

        oc-prom -->|"localhost:9090/api/v1/otlp"| pr-sc
        oc-otlp -->|gRPC| ja-col
        oc-opensearch -->|HTTP| os-http

        subgraph pr[Prometheus]
            style pr fill:#e75128,color:black;
            pr-sc[/"Prometheus OTLP Write Receiver"/]
            pr-tsdb[(Prometheus TSDB)]
            pr-http[/"Prometheus HTTP
listening on
localhost:9090"/]

            pr-sc --> pr-tsdb
            pr-tsdb --> pr-http
        end

        pr-b{{"Browser
Prometheus UI"}}
        pr-http ---->|"localhost:9090/graph"| pr-b

        subgraph ja[Jaeger]
            style ja fill:#60d0e4,color:black;
            ja-col[/"Jaeger Collector
listening on
grpc://jaeger:4317"/]
            ja-db[(Jaeger DB)]
            ja-http[/"Jaeger HTTP
listening on
localhost:16686"/]

            ja-col --> ja-db
            ja-db --> ja-http
        end

        subgraph os[OpenSearch]
            style os fill:#005eb8,color:black;
            os-http[/"OpenSearch
listening on
localhost:9200"/]
            os-db[(OpenSearch Index)]

            os-http ---> os-db
        end

        subgraph gr[Grafana]
            style gr fill:#f8b91e,color:black;
            gr-srv["Grafana Server"]
            gr-http[/"Grafana HTTP
listening on
localhost:3000"/]

            gr-srv --> gr-http
        end

        pr-http --> |"localhost:9090/api"| gr-srv
        ja-http --> |"localhost:16686/api"| gr-srv
        os-http --> |"localhost:9200/api"| gr-srv

        ja-b{{"Browser
Jaeger UI"}}
        ja-http ---->|"localhost:16686/search"| ja-b

        gr-b{{"Browser
Grafana UI"}}
        gr-http -->|"localhost:3000/dashboard"| gr-b
    end
end

DevOps

#

The full stack, including application, database, and observability infrastructure, is orchestrated with Docker Compose for a single command local deployment. The project also explores different container image strategies to address security and image size concerns:

• Standard: conventional single layer image
• Multistage: optimized multistage build separating dependencies from runtime
• Distroless: minimal runtime without shell or package manager
• Chainguard: hardened baseline with minimal attack surface

CI/CD is handled by GitHub Actions, automating test runs and publishing Docker images to Docker Hub on each release. Dependency updates are managed automatically via Dependabot.
